Tuesday, July 27, 2010

Other products in the market for arsenic detection and monitoring

Nowadays, there are lots of devices and products in the market for easy monitoring and detection of arsenic. You can even purchase one at home for your family to ensure that the water that you are drinking is arsenic-free! You might even purchase one for research purposes. Here are some of the products that you might want to consider:

Digipass arsenic detection device

Wagtech Arsenic detection kit

Arsine gas detector

LaMotte Arsenic detection kit

ORLAB arsenic detection kit

Hydrodyne arsenic detection kit

Purtest arsenic test

Arsenic Quick™ Wood Field Testing Kit

The Arsenic monitor

The ArsenicGuard

Monday, July 26, 2010

Surface Plasmon Resonance (SPR)

An innovative technology to detect arsenic in water is Surface plasmon resonance,SPR.

Working principle of a single beam SPR:

A light source will shone on the prism with a sensor chip attached on its surface, buffer will then flow through the prism .Hence, reflecting the light onto the mirror in a critical angle, where readings are taken down

Comparison of SPR with other analysis methods:

As compared to other analysis technologies, SPR can detect a smaller quantity of arsenic compound , making it more precise then other detection method,but high cost for this technology has offset its benefits.

Animation of SPR

Arsenic detection with gold nanoparticles

~ Arsenic detection with GOLD nanoparticles~

Arsenic detection with gold nanoparticles works with the aggregation of gold nanoparticles, and it selectively detects arsenic in drinking water down to concentrations of 3 ppt (parts per trillion).

Countries like India, Bangladesh, and Thailand are primarily affected by ground water with high arsenic concentrations. However, high concentrations of arsenic have also been found in some areas of North and South America. Once detected, the problem can fairly easily be addressed.

Current analytical techniques are time-consuming and require a series of enrichment steps.
The new process could now speed up and simplify arsenic analysis.

Special organic molecules were to the surfaces of the gold nanoparticles. These molecules act as ligands” for arsenic, meaning that they form a complex with it.

Each arsenic ion can bind to three ligands, which allows it to link together up to three gold particles.

The higher the arsenic concentration in the sample, the more strongly the gold particles clump together and the number of bigger aggregates increases.

The color of gold nanoparticles in a liquid depends on their size. Whereas the arsenic-free gold nano-particles appear red, arsenic-induced aggregation causes the color to change to blue.

Concentrations down to 1 ppb can be detected with the naked eye by means of the color change. Arsenic binds to the ligands much more strongly than other metals; the researchers were able to increase this selectivity by attaching three different ligands to the gold.

One very precise method for detecting minimal changes in particle size is dynamic light scattering (DLS), in which laser light scattered by the particles is analyzed. By using DLS, Ray and his co-workers were able to detect and quantify arsenic concentrations as low as 3 ppt. In samples of well water from Bangladesh, the team found 28 ppb arsenic; in water from taps in Jackson (Mississippi, USA) they found 380 ppt.

Sunday, July 25, 2010


Picture references:




Saturday, July 24, 2010

Anodic Stripping Voltammetry (ASV)

Electrochemical assays for arsenic detection such as this is very promising. This method is suitable for detection in liquid samples such as groundwater. It can be applied to solid samples as well, but the sample has to be digested or extracted before testing.

ASV is also suitable for measuring dissolved arsenic in drinking water and it is equally sensitive towards As (III) and As (V).

Although ASV can be used to monitor other kinds of elements, we will now only discuss on how it detects arsenic. Basically, it works based on the principle of electroplating arsenic onto an electrode, which concentrates it. The arsenic that is electroplated or reduced onto the electrode is then stripped off or oxidized off. We can control this electroplating and stripping off action by raising or lowering the potential, which will be discussed in detailed in the procedures. The stripping off action generates a current that can be measured. The current (milliamps) is proportional to the amount of arsenic being stripped off.
As ASV can be used to monitor other types of metals besides arsenic, it is necessary for us to identify the metal that is being stripped off; the potential (voltage in millivolts) will allow us to determine the characteristic for each metal. This allows us to both identify and quantify the metal that is being measured.

Anodic stripping voltammetry usually incorporates three electrodes, a working electrode, auxiliary electrode (sometimes called the counter electrode), and reference electrode. An electrolyte is usually essential for most samples. For most standard tests, the working electrode is a mercury film electrode. The mercury film forms an amalgam(mixture) with the analyte(the substance or sample being analyzed) of interest, which upon oxidation results in a sharp peak, improving resolution between analytes. The mercury film is formed over a glassy carbon electrode. A mercury drop electrode has also been used for much the same reasons. In cases where the analyte of interest has an oxidizing potential above that of mercury, or where a mercury electrode would be otherwise unsuitable, as the analyte will not be stripped off easily as it cannot be easily oxidized. Hence, we can solve this problem by using a solid, inert metal such as silver, gold, or platinum may also be used.

The detailed procedures are shown as below:

1. The solution is continuously stirred during the first 2 steps. The first step is the cleaning step where the potential is raised to a higher potential for a period of time to fully strip the metal off from the electrode.

2. The potential is then lowered to a lower potential so as to reduce the metal and deposit it on the electrode. After this second step, the stirring is then stopped.

3. If a mercury electrode is used, more time should be allocated to make sure that the deposited material is distributed evenly onto the electrode. If a solid inert electrode is used, this step may be skipped.

4. Lastly, the working electrode is then raised to a higher potential and the metal is stripped off or oxidized. This stripping action will give off electrons, which is a measure of the current.

A: Cleaning step, B: Electroplating step, C: Equilibration step, D: Stripping step

The effect of electroplating and stripping on the graph


-The instrument is portable, lightweight, and field ready with long battery life (up to 40hours)

-good detection limit (0.1µg/L) as it can measure arsenic at low levels


-requires the hands of a professional to operate some operations

-high degree of instrument maintenance-instrumentation required is relatively expensive to purchase ($30,000)

-not approved by EPA as an acceptable analytical technique for measuring arsenic concentrations in drinking water

-results are interfered by the presence of other elements such as copper, mercury and zinc.

Nano-Band Explorer : an electrochemical analyzer capable of performing Anodic Stripping Voltammetry (ASV)


After discussing on the monitoring technologies mentioned above, it still remains a technical challenge to measure arsenic accurately in a short time. Although the monitoring instruments and methods mentioned above as its individual advantages, the central goal of developing field assays that reliably and reproducibly quantify arsenic has not been achieved.

Although the technologies mentioned above are less capable of measuring organoarsenic compounds, it should still be taken into account to comprise an important fraction of the total environmental arsenic as it is also considered a toxic pollutant. However, it is less toxic than inorganic arsenic. Arsenic sulfur species should be taken into consideration as well.

Friday, July 23, 2010

Removal of arsenic

Arsenic which exists in the form of arsenate or As(V), which are commonly found in aerobic surface waters are more easily removed compared to that of arsenite or As(III), which is common in anaerobic ground water. Hence, the removal technologies shown below are more effective in removing arsenate or As(V). The reason for this is due to the difference in charges of arsenate and arsenite, with arsenate being negatively charged and arsenite being neutral in charge.

If however, arsenite is predominant in the water sample, it can be oxidized into arsenate by pre-oxidation to arsenate. Some of the oxidizing agents that we can use include chlorine, ferric chloride, and potassium permanganate. Another alternative is by using ozone and hydrogen peroxide, but they might not be as effective as no data are available on performance.
Besides removing arsenic using the technologies mentioned below, there are three basic methods that we can prevent arsenic exposure:
1. treating arsenic contaminated groundwater
2. drawing water from uncontaminated acquifers.
3. using water from other sources such as rivers, rainfalls or ponds.
However, this may not be practical for certain regions which does not have the necessary technologies or sources, especially in poor countries like Bangladesh.

Current technologies for arsenic removal

Coagulation/Filtration (C/F) is an effective treatment process for the removal of arsenic. The efficiency of this process is affected by pH as the efficiency will be reduced when the pH becomes too high or too low. One main cause of concern is that the nearby landfills may not be willing to accept this arsenic-contaminated coagulation sludge for disposal. Hence, disposal of sludge may be a problem. Well trained operators may be required for this process. This process is also very costly and the process performance may vary.

Lime Softening (LS) provides a high efficiency for arsenic removal under certain conditions. It has to be conducted at a pH of greater than 10.5 provided that the influent concentration is 50 µg/L. However, in order to further reduce the concentration of the pollutant, it may require a secondary treatment process. The following diagram shows the process of lime softening.

Activated Alumina(AA) is effective for treating water that has a high concentration of Total Suspended Solids(TDS). However, other elements such as selenium, fluoride, chloride, and sulphate, when present at high concentrations, may interfere with the removal process. This removal process is highly selective towards arsenic. One cause of concern that it may not be efficient in the long term, as it loses its adsorptive capacity with time. As this process releases highly concentrated waste streams, disposal may be a problem as well.

Ion Exchange (IE) is effective for removing arsenic. However, sulfate, TDS, selenium, fluoride, and nitrate can also interfere with the removal process. Systems containing high levels of these constituents may require pretreatment. As this process produces highly concentrated waste by-product stream, disposal may be a problem as well. The following diagram shows the process of ion exchange.

Reverse Osmosis (RO) is able to remove as much as 95% of arsenic when the right amount of operating pressure is applied. This removal process may not be suitable to be used in water-scarce regions due to water rejection.(about 20-25% of influent).

Electrodialysis Reversal (EDR) is able to achieve a removal efficiency of 80%. Studies have shown that this process can reduce an influent concentration of 21 µg/L to only 3 µg/L, which shows a decrease in 19 µg/L of arsenic concentration. Similar to reverse osmosis, there is water rejection as well. Compared to RO, this process may not be cost competitive and as efficient. However, it is easier to operate. The following diagram shows a diagram of the EDR module.

Nanofiltration (NF) can achieve a removal efficiency of over 90%. However, this method of removal might not be suitable for regions where water is scarce as the water from the influent may be rejected by as much as 25%.

Recent breakthroughs of arsenic removal

Instead of using the conventional man-made techniques to remove arsenic as mentioned above, we can now use bacteria to remove arsenic. Scientists have recently discovered a new kind of microbe that posses the ability to use this poison to turn sunlight into food. In other words, it uses arsenic to power photosynthesis, which is a process whereby plants and bacteria convert sunlight into food. This bacteria is found in a hot spring in California as they have the ability to thrive in hot temperatures. However, the bacteria can only perform this removal in the presence of sunlight, which is a basic requirement for the process of photosynthesis.

The red slime mat shown in this picture is made up of the bacteria that uses arsenic to power photosynthesis.

Tuesday, July 20, 2010

What are the sources?

Natural sources of arsenic

Contaminated food [Seafoods]

Ground water used for drinking water supply

volcanic action


Low temperature volatilization


    Man-made sources


    • ore smelting/refining/processing plants, galvanizing, etching and plating processes

    burning of fossil fuels especially in coal-fired power generation plants

    Tailings from or river bottoms near gold mining areas (past or present)

    Agricultural chemicals: Insecticides, rodenticides and fungicides

    Commercial arsenic products which include: sodium arsenite, calcium arsenate, and lead arsenate.

    • "Paris green" (cupric acetoarsenite) a wood preservative.

    Burning of vegetation

    Ore smelting at an industry

    A global phenomena

    Bangladesh is not the only country with arsenic pollution of the groundwater, but pollution is exceptionally widespread around the world.

    Many other countries and districts in South East Asia, such as Vietnam, Cambodia, and China have geological environments conducive to generation of high-arsenic groundwater.

    Footage of people suffering due to arsenic poisoning in bangledesh

    Thursday, July 15, 2010

    Portable X-ray Fluorescence

    X-ray fluorescence (XRF) is the emission of characteristic "secondary" (or fluorescent) X-rays from a material that has been excited by bombarding with high-energy X-rays or gamma rays. Besides measuring arsenic, it can be used to analyse other elements and chemicals like the investigation of metals, glass, ceramics, and building materials and for research in geochemistry, forensic science and archaeology. The following diagram shows the basic working principle of this process.

    The amount of photon emitted will help us determine the concentration of the arsenic in the sample. A photon is a  discrete bundle of light energy.

    Portable X-ray fluorescence is used to measure arsenic in dry solid samples, such as soil and dried sludge. The main interferents listed in this method were variations in particle size, moisture, and lead co-contamination.


    -Measuring devices are normally portable

    - It can directly measure arsenic in the soil without having to extract the soil from the ground.

    - Can measure a wide variety of metals besides arsenic

    - Flexible as it can be used for measuring arsenic in both liquid and solid samples.


    -It is not suitable for the detection of low concentrations of arsenic especially in drinking water as detection is only accurate at gram per litre concentrations.

    -results can be interfered when lead is present in the sample

    -many models contain a radioactive source, which may cause health effects to the user if not properly handled. However, research efforts have proven that this radioactive source can be eliminated and replaced by a less harmful source.

    The Wagtech Arsenator system

    A quick and portable device available in the market to detect concentration of arsenic.

    The complete system comes with sufficient reagents and consumables for over 400 tests. The following are the advantages of using the Arsenator:

    Low cost digital arsenic testing device

    Fully portable, designed specially for field use

    Immediate results in the field in less than 20 minutes

    Simple, safe and easy to operate

    Gives accurate test results between the critical range of 2µgl (ppb) to 100µgl (ppb)

    • Designed in conjunction with Prof. Walter Kosmus and laboratory tested by Imperial College London

    • Field tested in conjunction with UNICEF/WHO WAT/SAN monitoring programmes

    Environmentally friendly

    Colorimetric Test Kits

    Detection using field test kits are very common and are used extensively to monitor arsenic in groundwater. This method of detection is based on the "Gutzeit" method which is developed over 100 years ago. Besides using it for detection in water samples, it can also be applied to testing solid waste and soil by acid extraction or acidic oxidation digestion of the sample.

    The following illustrates the procedures of the “Gutzeit” method :

    1. treat the water sample with a reducing agent that transforms the arsenic compounds present in the water into arsenic trihydride (arsine gas).

    2. Arsenic is separated from the sample

    3. The arsenic trihydride diffuses out of the sample where it is exposed to a paper impregnated with mercuric bromide.

    AsH3 + 3HgBr2 → As(HgBr)3 + 3HBr

    The white mercury(II) bromide will turn yellow, brown, or black if arsenic is present in the sample

    4. The reaction with the paper produces a highly colored compound.

    5. The concentration of the arsenic can be approximated using a calibrated color scale.

    This method of detection has several pros and cons as shown below.


    • inexpensive
    • minimally trained personnel can readily perform it and read the results in the field.


    • sulfur, selenium, and tellurium compounds have the potential of interfering with this assay.

    Using Bacteria and Plants for Arsenic Detection

    Instead of using conventional man-made technologies, can you all imagine using bacteria and plants for arsenic detection?Let's take a look at this innovative bio-technology that has been developed.

    Although biological monitoring may be a more sustainable way of monitoring arsenic, the decision of whether this method may be suitable or not depends on the purpose and the reseources available for a particular investigation.

    One of the advantages of biological monitoring is the fact that there is a close association between biomonitors with the biological systems under study as it the biomonitor is normally part of the biological system.

    Criteria for selecting good biological monitoring species include:

    -the organism must be capable of accumulating metals in measurable amounts.

    -the organism, or relevant parts of it, must be readily available both in terms of quantity and distribution so that unbiased sampling is possible.

    -it should be available throughout the year or throughout the period of study, with relative ease of collection.

    -Upon exposure, the organism should show a differential uptake or accumulation which allows us to determine the relative pollution levels and establish a relationship to deposition rate or air concentrations.

    -the organism should not ingest metals from other sources, this is especially important for assesing airborne contamination.

    -repeatability is essential

    -reasonable cost of collection and analysis


    Research has shown that bacteria can be used as a biosensor to identify and treat sites that are contaminated with arsenic. Although bacteria has been used to monitor nitrates in the past, the use of microbes to treat arsenic may also be feasible, according to scientists.

    All cell-based organisms have the ability to detoxify arsenic compounds. The process involves a wide variety of proteins that will modify, transport and extrude the arsenic from the cell. In the presence of arsenic and through specific genetic mechanisms, the correct sequence of proteins can be synthesised and activated. Hence, the required proteins can be synthesized to activate the arsenic detoxification system.

    Due to the fact that the correct sequence of genes is necessary to produce the desired protein, it is absolutely necessary that we understand the identity, specificity, and sensitivity of the genetic elements and their corresponding regulatory proteins when employing biosensors. In order to create a biosensor that can monitor arsenic, the arsenic-responsive DNA control sequences are linked to an additional gene which is called the reporter gene. This gene produces a protein that can produce an obvious response for easy detection as it produces a highly coloured material or fluorescent protein. With the advancement in genetic engineering, we can now produce microbes that generates a visible signal (i.e.fluorescent bright yellow), when it comes into contact with arsenic compounds.

    Diagram showing how a reporter gene is made

    These test tubes are filled with fluorescent proteins that are highly coloured

    Genetically modified microbes were used in another recent study to develop a set of semi-quantitative assays for potable water. The investigators also developed an assay that produced a visible blue color with arsenite concentrations above 8 ppb.
    The following illustrates some of the advantages and disadvantages of using this method:


    - can detect arsenic down to ppb levels, in other words, it can measure only small concentrations of arsenic

    -good potential for assaying arsenic

    -environmentally friendly


    -apply only to water assays

    - limited success rate

    - it is not clear whether the microbes are measuring all of the arsenic in a sample or just the bioavailable arsenic.


    Compared with the use of microbes for arsenic detection, there are far less research involving the use of plants to detect arsenic. A recent experiment has been conducted on two water plants upon exposure to arsenic. It is found that there is a change in the colour pigments of the plants. In order to acquire more accurate results, it requires an incubation period of three days and quantified with a series of standards. Although this is a very sustainable and "low tech" assay, the results may be affected by other factors such as nutrient levels or microbial infection, which can generate the same pigment change as arsenic absorption.

    If we are to consider using plants to monitor arsenic, it is necessary that we take into account of the factors that affect the efficiency of particulate capture and retention. This includes the size, shape, canopy structure and surface characteristics of the plants or plant organs as well as the degree of exposure. In addition to this, we also need to consider the relationship between the surface area and weight of the plant organs as these factors will affect the expression of the results and may cause the intepretation and comparison of the data to be very complicated.

    Here are some of the advantages and disadvantages of using this method:


    -its general ubiquity. Only in situations of extreme aerial contamination is vegetation likely to be sufficiently scarce to cause sampling problems. In other words, this detection method has a low risk for sampling problems to occur.


    - coloration changes in plant systems may be due to factors other than arsenic detection.

    -samples may vary between general herbage of several species to leaves, whole leafy shoots and bark of single species.

    Recent breakthroughs for arsenic detection using bacteria

    A student team from the University of Edinburgh has used genetically engineered bacteria to detect arsenic in water. In combination with a drop of pH indicator (far right), samples turn red (middle) in the presence of arsenic and yellow in its absence.

    For more information ,feel free to read up more on : http://www.technologyreview.com/Biotech/18103/
